Applied in the dyeing and finishing industry, including setting machines, singeing machines, gluing machines, washing machines, drying machines
The feeding point on mechanical equipment such as printing machines
Applicable to woven, knitted, and non-woven fabrics
Suitable for dry, slightly wet, and dripping fabrics
● Infrared signal detection
Control mode: continuous action
| Working power supply | 220V AC ± 10%/24VDC |
| Edge accuracy | ± 5mm |
| Working environment temperature | 0-50 ℃ |
| output | Two sets of normally open and normally closed contacts on the left and right sides |
| response speed | 50ms |
| Maximum fabric speed | 120m/min |
| Applicable door width | 800-2200mm |
| Resistant to ambient light | Lighting below 5000LUX |
| Sealing level | IP6 acid and alkali resistant |
| material quality | Internal: Aluminum alloy External: High temperature resistant plastic |
| Applicable scope | Industries such as textiles, papermaking, printing and dyeing |
